Modelling and Coordinated Control of Grid Connected Photovoltaic, Wind Turbine Driven PMSG, and Energy Storage Device for a Hybrid DC-AC Microgrid

Abstract: This paper proposes the enhancement of the flexibility and controllability of the grid connected converter (GCC), this paper proposes a common DC bus voltage maintenance and power sharing control strategy of a GCC for a DC/AC microgrid. A maximum power point tracking algorithm is employed to enhance the power delivered by the wind turbine and photovoltaic module. The proposed control strategy consists of primary and secondary aspects. In the primary layer control, the DC bus voltage is regulated by the GCC. In the secondary layer, the DC bus voltage is maintained by the energy storage device. This ensures reliable power for local loads during grid failures, while power injection to the grid is controlled by an energy management algorithm followed by reference generation of inductor current in the GCC. The proposed control strategy operates in different modes of DC voltage regulation, power injection to the grid and a hybrid operating mode. It provides wide flexible control and ensures the reliable operation of the microgrid. This was implemented in 2018a Matlab Software.

Keywords: Wind energy, photovoltaic energy, DC/AC microgrid, battery energy storage system, co-ordinated control.
