Miller Compensation using CMOS OPAMP employing Current Buffer
Also Available Domains Tanner EDA|Cadence EDA
Objective
The main objective of this paper is to improve the stability of OAMP by using Miller Capacitor.
Abstract
In this paper we design an Operational amplifier with Mill operator capacitor. The plan strategy of the two-stage CMOS functional intensifiers utilizing Mill operator capacitor related to the normal door current cushion is introduced. By using this circuit, the lower frequencies are higher than the channel remove recurrence. The miller compensation was compared with the uncompensated method and then the compensation method was proposed and then the ideal gain characteristics are improved. This circuit is implemented on LT-SPICE with 45nm technology.
Index Terms—Miller Compensation, op-amp.
