Design & Implementation of Wallace Tree Multiplier and Kogge Stone Adder

An increment in demand of portable devices makes low power device design and becomes an important field of research. Delay is one of the main design objective in integrated circuits after power. Three parameters which are power, area, and delay are always trade off. However speed and area are usually conflicting constraints, so that speed improvement results mostly in larger area. The multiplication and addition of two binary numbers are the most frequently and fundamental used arithmetic operations in microprocessors, data-processing application specific integrated circuits and digital processors. This research work will focuses on analyzing the delay of a Wallace tree multiplier and a carry select Adder by optimizing their circuits to increase the speed of the different digital circuits which are used in computations. Multipliers and adders are most important part in the digital processing or other applications. Therefore, multipliers and adders should be designed in such a way that their speed would be high and delay would be low. In the full paper, the full implementation and simulation results will be discussed. Great results have been achieved and comparison study has also been done with previous research work.
