An Energy Management Strategy of Hybrid micro grid Systems for agricultural applications
Objective
The main objective of this project is to design a hybrid micro grid systems like SPV system, hydro system and grid.
Abstract
In this project, the design of a solar PV system through a perturb and observation maximum power point tracking (MPPT) algorithm is proposed. SPV system in conjunction with P&O MPPT technique driven DC-DC boost converter enhances the output voltage besides tracking maximum power point (MPP) under varying irradiance in between 0-1000 W/m2 and a constant temperature of 25 °C.
The objective of this study is to operate the designed SPV system at MPP under varying environmental condition in order to achieve higher efficacy, minimize overall system cost and obtain apropos voltage and current. This paper focuses on the operation of a PV/hydro energy system, grid by using a fuzzy logic controller to improve the system efficiency, reduces the total harmonic distortion. In this system, reliability and continuity of power supply at a constant voltage have been considered as problem constraints.
Keywords: Photo Voltaic, Hydro systems, P&O, PI, Fuzzy logic controller, boost converter
NOTE: Without the concern of our team, please don't submit to the college. This Abstract varies based on student requirements.
Block Diagram
Specifications
Software Configuration:
Operating System : Windows 7/8/10
Application Software : Matlab/Simulink
Hardware Configuration:
RAM : 8 GB
Processor : I3 / I5(Mostly prefer)
Learning Outcomes
- Introduction to Matlab/Simulink
- What is EISPACK & LINPACK
- How to start with MATLAB
- About Matlab language
- About tools & libraries
- Application of Matlab/Simulink
- About Matlab desktop
- Features of Matlab/Simulink
- Basics on Matlab/Simulink
- Introduction to solar power generation
- Introduction to Matlab/Simulink software
- Introduction to power electronics converters
- Introduction to phase locked loop (PLL)
- Design of PLL
- Introduction to solar PV system.
- Introduction to PID controller.
- Design of PID controller.
- Design of battery energy storage system
- Design of solar PV system
- Design of MPPT controller
- Design of Power electronic converters.
- We can learn about the generation of gate pulses to the converter
- We can learn about the bidirectional DC -DC converter operation
- Project Development Skills:
- Problem analyzing skills
- Problem solving skills
- Creativity and imaginary skills
- Programming skills
- Deployment
- Testing skills
- Debugging skills
- Project presentation skills
- Thesis writing skills
