Adaptive Control of Voltage Source Converter Based Scheme for Power Quality Improved Grid-Interactive Solar PV- Battery System

This paper presents an implementation of an Adaptive Learning Based Back Propagation (AL-BP) control technique for improved power quality grid interactive solar PV - battery supported system catering the balanced and unbalanced three phase four wire (3P-4W) nonlinear loads and single phase loads of various nature simultaneously. Moreover the source currents remain balanced and sinusoidal for all operating and loading conditions such as in highly unbalance loading conditions where a load on one of the phase is disconnected. An AL-BP control technique is used to control the voltage at point of common coupling and to improve power quality under various loading conditions through mitigation of harmonic currents, reactive power compensation, active power balancing and neutral current compensation in the 3P-4W system. It also improves the system power factor in highly nonlinear and unbalanced loading conditions. The AL-BP control scheme has the capability to self-tune the arbitrary nonlinear systems such as grid-interactive critically unbalanced 3-phase 4-wire system feeding highly nonlinear loading systems. Therefore, the proposed control technique is found capable of dealing with above said large unknown-nonlinearity of 3-phase 4-wire system. This scheme significantly improves the steady state and dynamic performances of the 3 phase 4 wire (3P-4W) grid interactive solar PV - battery supported system. The proposed AL-BP control technique has been implemented using DSP processor in real time in order to validate the claims.

Index Terms— Solar PV, VSC, power quality, non-linear loads, integrated system.
