A 0.6-V Low-Power Variable-Gain LNA in 0.18-um CMOS Technology

Project Code :TVPGBE161

Objective

By using the forward body biasing, input feedback capacitor, current-reuse and multiple-gate topologies, the LNA can achieve low power consumption, small chip area, and high linearity.

Abstract

A proposed low-power, variable-gain low-noise amplifier operates at 0.6 volts and employs a CMOS process. The design utilizes tunable negative-feedback capacitor technology to achieve variable gain. Furthermore, it leverages forward body biasing, input feedback capacitors, current-reuse techniques, and multiple-gate topologies to attain objectives of low power consumption, compact chip size, and high linearity. Measurements demonstrate power and a Noise figure. The amplifier's power consumption is impressively low.

Keywords: — LNA, CMOS, variable gain, high linearity, low power consumption..
